Транзистор MPS3638A

• Структура - p-n-p
• Напряжение коллектор-эмиттер, не более: -25 В
• Напряжение коллектор-база, не более: -25 В
• Напряжение эмиттер-база, не более: -4 V
• Ток коллектора, не более: -0.5 А
• Рассеиваемая мощность коллектора, не более: 0.625 Вт
• Коэффициент усиления транзистора по току (h_fe): от 100
• Корпус: TO-92

Транзистор MPS3638A можно заменить на 2SA1013O, 2SA1020U, 2SA1270-Y, 2SA1271, 2SA1271-O, 2SA1271-Y, 2SA1273, 2SA1273-O, 2SA1273-Y, 2SA1275-O, 2SA1275-Y, 2SA1283-E, 2SA1284-E, 2SA1287, 2SA1287-G, 2SA1315-Y, 2SA1319, 2SA1319-R, 2SA1319-S, 2SA1319-T, 2SA1382, 2SA1533-R, 2SA1534-R, 2SA1534-S, 2SA1534A-R, 2SA1534A-S, 2SA1619-R, 2SA1619-S, 2SA1619A-R, 2SA1619A-S, 2SA1625-K, 2SA1680, 2SA1761, 2SA1972, 2SA200-Y, 2SA562TM-Y, 2SA683-R, 2SA683-S, 2SA684-R, 2SA684-S, 2SA719-R, 2SA719-S, 2SA720-R, 2SA720-S, 2SA777-R, 2SA928A, 2SA928A-O, 2SA928A-Y, 2SA935-Q, 2SA935-R, 2SA950, 2SA950-O, 2SA950-Y, 2SA952-K, 2SA952-L, 2SA965-Y, 2SA966, 2SA966-O, 2SA966-Y, 2SA984-E, 2SA984-F, 2SA984K-E, 2SA984K-F, 2SA993C, 2SA993D, 2SB1116, 2SB1116-K, 2SB1116-L, 2SB1116-U, 2SB1116A, 2SB1116A-K, 2SB1116A-L, 2SB1116A-U, 2SB1116AK, 2SB1116AL, 2SB1116K, 2SB1116L, 2SB1116U, 2SB560-E, 2SB560-F, 2SB560-G, 2SB564K, 2SB564L, 2SB621-R, 2SB621-S, 2SB621A-R, 2SB621A-S, 2SB647AC, 2SB647C, 2SB647D, 2SB740, 2SB740-B, 2SB740-C, 2SB764-E, 2SB764-F, 2SB892, 2SB892-R, 2SB892-S, 2SB892-T, 2SB892-U, 2SB985, 2SB985R, 2SB985S, 2SB985T, 2SB985U, 2SC1317-R, 2SC1317-S, 2SC1318-R, 2SC1318-S, BC876, BC878, BC880, KSA1013O, KSA1013Y, KSA1281-Y, KSA1625-K, KSA708CY, KSA709CG, KSA709CY, KSA916Y, KSA928A, KSA928A-O, KSA928A-Y, KSA931Y, KSB1116, KSB1116-G, KSB1116-L, KSB1116-Y, KSB1116A, KSB1116A-G, KSB1116A-Y, KSB1116S, KSB1116S-G, KSB1116S-L, KSB1116S-Y, KSB564ACG, KSB564ACY, KSP2907AC, KSP8598C, KSP8599C, KTA1270Y, KTA1271, KTA1271O, KTA1271Y, KTA1272, KTA1272O, KTA1272Y, KTA1273, KTA1273O, KTA1273Y, KTA1275O, KTA1275Y, KTA1277Y, KTA1281Y, KTA1282, KTA1282O, KTA1282Y, KTA1283GR, KTA1283Y, KTA200-Y, KTA708-Y, KTB764-GR, KTB764-Y, NTE193A, NTE383, PN3638A, STB1277, STB1277-O, STB1277-Y
